WIFI：
|
Chipset |
RTL8821CU |
|
|
WiFi Standard |
IEEE802.11ac/a/n/g/b |
|
|
Interface |
USB 2.0 |
|
|
Antenna |
Build-in Ant |
|
|
Coverage Distance |
Indoor MAX：100M |
|
|
Frequency |
2.412~2484GHz/5.15~5.825GHz |
|
|
RF Power |
802.11b (CCK) 11Mbps: 18+/-1dBm |
|
|
802.11g (OFDM) 54Mbps: 15+/-1dBm |
||
|
802.11n(OFDM)150Mbps: 15+/-1dBm |
||
|
802.11ac（AC80）MCS9：12+/-2dBm |
||
|
EVM |
11b 11Mbps:＜-15db 11g 54Mbps:＜-27db 11ac MCS9：＜-30db |
|
|
Receive sensitivity |
802.11b: -76+/-1dBm；802.11g: -65+/-1dBm |
|
|
802.11n (HT20), -70+/-1dBm；802.11n (HT40), -65+/-1dBm |
||
|
AC80-MCS9：-55+/-1dBm |
||
|
Speed |
11b: Max 11Mbps,11g:Max 54Mbps ,11n:Max 150Mbps,AC:Max 433Mbps |
|
|
Vlotage |
5V DC±5%V DC/<220mA（MAX） |
|
|
Consumption |
RX/TX：220mA（max） |
|
|
TX：220mA（max） |
||
|
RX：180mA（max） |
||
|
Operation System |
Windows XP/Vista/7/8/10 |
|
|
Wireless security |
WPA/WPA2/WEP/802.1X/WMM; |
|
|
Hardware |
||
|
Size |
32*16*7mm 127*100*17mm |
|
|
Weight |
38g |
|
Bluetooth function：
| Bluetooth version | Bluetooth2.1 / Bluetooth 4.2 |
| Antenna reference | Small gain peak antenna for 0~2dBi |
| working frequency | 2.4G:2.4000GHz~2.4835GHz |
| channel | 0~78 channel |
| modulation | 8DPSK,π/4 DQPSK,GFSK |
| Transmission range | Within 10 meters |
| transmission speed |
1Mbps basic rate 2.3Mbps post enhancement rate |
| Maximum input level |
GFSK(1Mbps): -20dBm π/4-DQPSK(2Mbps) 8DPSK(3Mbps) |
| Environmental requirements |
Working Temperature: -10℃ ~ +50 ℃
Storage Temperature: -20℃ ~ +50 ℃
Temperature: 10% ~ 95% does not condense |
| support system | Win7/Win8/Win10 |
