PRODUCT
What this Product Does
MT7628K 300Mbps Easy Setup Router is designed to setup more easily for the home user. It complies with IEE802.11n, delivers wireless speeds of up to 300Mbps, making it perfect for everyday web activities like email, chat, streaming videos, online gaming and more. The Wro8 can also work as a client router to connect ISP network wirelessly or uplink AP to share the Internet to every corner, elimating the dead point.
Superior performance
4*5dBi external antennas boost WIFI to each corner of your house. You can enjoy entire-home WIFI coverage and lag free WIFI performance.
Datasheet:
|
Interface |
3x10/100Mbps LAN PORTS 1x10/100Mbps WAN PORTS |
|
Antenna |
4*5dBi Fixed Omni Directional Antenna |
|
External Power Supply |
5V DC/1A |
|
Wireless Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|
Dimensions(WXDXH) |
199 x 106 x 27 mm |
|
Frequency |
2.4-2.4835GHz |
|
Signal Rate |
Up to 300Mbps(dynamic) |
|
Reception Sensitivity |
270M:-70dBm@10%PER |
|
Transmit Power |
<20dBm |
|
Wireless Functions |
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
|
Wireless Security |
64/128/152-bit WEP/WPA/WPA2, WPA-PSK/WPA2-PSK |
|
Quality of service |
WMM, Bandwidth Control |
|
WAN Type |
Dynamic IP/Static IP/PPTP/L2TP/BigPond |
|
DHCP |
Server, Client, DHCP Client List |
|
Port Forwarding |
Virtual server, port Triggering, UPnP, DMZ |
|
VPN Pass-Through |
PPTP, L2TP, IPSec(ESP Head) |
|
Firewall Security |
DoS, SPI Firewall IP Address Filter/MAC AddressFilter/Domain Filter IP and MAC Address Binding |
|
Package Contents |
1*wireless-AC Router 1*Power Adapter 1*Ethernet Cable 1*Quick Installation Guide |
|
Environment |
Operating Temperature: 0℃~40℃(32℉~104℉) Storage Temperature: -40℃~70℃(-40℉~158℉) Operating Humidity: 10%-90% non-condensing Storage Humidity: 5%-90% non-condensing |
